Our Cat6A S/STP lan cable is high bandwidth and high performance cable for applications at gigabit speed and full duplex transmissions. Cat6A S/STP lan cables have a guaranteed performance; exceeds the Cat6A S/STP performance requirements and provides positive PSACR up to 500MHz for bandwidth requirement in the future.

• Tape design engineered for smaller overall diameter and ease of installation.
  Positive PSACR up to 500MHz for future bandwidth requirements.
  23 AWG, Twisted-Pair, Solid Bare Copper conductors, PE insulation, rip cord, industrial grade PVC / LSZH (Low Smoke Zero Halogen) outer jacket, sequential marking at one meter intervals.

• Outer Jacket:
  Outer Shield Material: Unshielded
  Outer Jacket Material: PVC / LSZH (Low Smoke Zero Halogen)
  Outer Jacket Ripcord: Yes
• Electrical Characteristics:
  Spark Test: 2,000±250 VOC
  Dielectric Strength: 1,000V dc/3 seconds
  Insulation Resistance:  Min. 150M/KM
  Conductor Resistance:  Max. 9.38/100m-at-20°C
  Resistance Unbalance:  Max. 2%
  Capacitance Unbalance: Max. 330pF/100m Mutual Capacitance: Max. 560pF/100m
• Cable Properties:
  Minimum Bending Radius Installed: 10 x D
  Maximum Tensile Load, Installation: 100N
  Maximum Tensile Load, Installed: No Stretch
• Mechanical Characteristics:
  Operating Temperature Range: -25°C To +70°C
  Installation Temperature Range: -10°C To +70°C

• TIA/EIA-568-B.2-1 Specifications
  TIA/EIA-862 (Building Automation)
  ISO/IEC 11801 Ed. 2.0 (Class E)
